Stewart Pro Series Trailer
The Stewart Pro Series Trailers are built for durability, versatility, and reliable performance in demanding agricultural tasks. Constructed with robust Hardox steel, they combine strength with manoeuvrability and offer ample capacity to handle heavy loads. With a range of customisable options, these trailers can be tailored to meet specific operational needs.
Capacity & Dimensions:
- Carrying capacity: 18 t, 23 m³
- GVM: 25 t
- 250 × 150 RHS chassis box section (top chassis 150 × 100)
- Hardox 4 mm floor, 6.7 m long × 2.45 m wide
- Hardox 3 mm sides, 1.5 m high
Key Features:
- Hydraulic up-and-over tailgate with NZ grain chute (400 × 400 mm)
- Twin underbody chrome rams
- Tandem sprung axles, 4 leaves per spring
- Sprung drawbar with swivel eye
- Hydraulic brakes
- Front mudguard flaps
- Commercial LED lights, flashing warning light, and 6 side LEDs
Optional Extras:
- Hydraulic load sensing
- Hydraulic jack stand
- Grain chute work lights
- Roll-over cover
- Upgraded tyres
- Bale extension
- Silage sides
- Air brakes
| PS 18 23 H | |
| Carrying capacity (kg): | 20,000 |
| Cubic capacity - Grain (m³): | 23 |
| Cubic capacity - Silage (m³): | 39 |
| Chassis: | 250x150 RHS box section |
| Unladen weight (kg): | 5,900 |
| Height to top rail (mm): | 2850 |
| Tipped height (mm): | 7150 |
| Body (mm): | 6700x2450x1500 |
| Axles (mm): | 125 Ø 10 stud, 420x180 brakes |
| Suspension: | Mechanical suspension with 4 leaf springs |
| Tipping mechanism: | Twin 3 stage 4.25” Ø chrome plated tipping rams |
